Accurate MySQL Replication Lag Detection in Production Environments

Background​
MySQL 5.7 reached its End-of-Life (EOL) in October 2023, yet many production systems still rely on this version. Recently, a large-scale transaction execution caused significant replication lag in a MySQL 5.7-based system, leading to data inconsistency between the primary and secondary databases. This impacted application logic due to read/write splitting. To address this, the business team urgently needed an accurate method to measure replication lag.

​Key Questions​

1. How can we obtain the actual replication lag value?
2. How do we ensure the measured value is reliable?

​Analyzing Seconds_Behind_Master’s Reliability​
The Seconds_Behind_Master metric from SHOW SLAVE STATUS indicates the delay in applying binary log events on the secondary. However, its accuracy is questionable:

• ​Calculation Flaws: It relies on timestamps from binary log entries, which may not reflect actual execution times (e.g., sync_binlog=0 delays log flushing).
• ​Single-Threaded SQL Thread Limitations: Long transactions (e.g., bulk updates) pause timestamp updates until completion, causing sudden spikes in reported lag.
• ​Parallel Replication Gaps: When using slave_parallel_workers, the metric only tracks the last applied event, masking delays in other threads.
• ​Network/I/O Overlooked: It ignores delays in log retrieval or relay log writes, potentially showing zero lag despite network issues.

​Solution: pt-heartbeat​
Percona Toolkit’s pt-heartbeat injects periodic timestamps into a monitoring table on the primary and measures lag by comparing them against the secondary’s clock:

1. ​Primary Setup:

-- Create heartbeat table
CREATE TABLE heartbeat.heartbeat (
  id INT PRIMARY KEY,
  ts TIMESTAMP(6) NOT NULL,
  server_id INT NOT NULL
);

-- Insert/update heartbeat every second
pt-heartbeat --host=primary_host --user=user --password=pass \
  --create-table --update --interval=1 -D heartbeat

‍

2. Secondary Monitoring:

pt-heartbeat --host=secondary_host --user=user --password=pass \
  --monitor -D heartbeat

‍

​Why pt-heartbeat is Reliable​

• ​Real-Time Precision: Updates every second with microsecond granularity.
• ​Clock Independence: Avoids reliance on MySQL’s internal timestamps by using the system clock.
• ​Parallel Replication Handling: Aggregates delays across all replication threads.
• ​Network Awareness: Accounts for propagation delays between primary and secondary.

​Recommendations​

• Deploy pt-heartbeat with intervals ≤ 0.5 seconds for balanced accuracy/load.
• Ensure NTP synchronization between primary/secondary to avoid clock drift.
• Set alerts for lag thresholds (e.g., >1s) and optimize large transactions.

By replacing Seconds_Behind_Master with pt-heartbeat, teams gain actionable insights into replication health, ensuring data consistency and system stability.

‍
